3.5mm Locking Clavicle Hook Plate

3.5mm Locking Clavicle Hook Plate

3.5mm Locking Clavicle Hook Plate

Specifications

  • Available in both Titanium & Stainless steel.
  • Plate features locking compression holes and round locking holes that accepts 3.5mm cortical and locking
  • Plates are available with 3 different hook depths, i.e, 12mm, 15mm & 18mm.
  • All the three depth plates bears 3,4,5,6 & 7 holes.



Indications for use

3.5mm Locking Clavicle Hook Plate is used to treat following fractures:

  • Lateral clavicle fractures: Neer type II or Jäger and Breitner type II.
  • Acromioclavicular joint dislocation type: Tossy III or Rockwood III to V.
get quote

Product Specifications

Specifications

  • Available in both Titanium & Stainless steel.
  • Plate features locking compression holes and round locking holes that accepts 3.5mm cortical and locking
  • Plates are available with 3 different hook depths, i.e, 12mm, 15mm & 18mm.
  • All the three depth plates bears 3,4,5,6 & 7 holes.



Indications for use

3.5mm Locking Clavicle Hook Plate is used to treat following fractures:

  • Lateral clavicle fractures: Neer type II or Jäger and Breitner type II.
  • Acromioclavicular joint dislocation type: Tossy III or Rockwood III to V.
Holes Hook Depth Stainless Steel (Right) Titanium (Right) Stainless Steel (Left) Titanium (Left)
3 12 mm 2-150-312R 2-150-312R-Ti 2-150-312L 2-150-312L-Ti
3 15 mm 2-150-315R 2-150-315R-Ti 2-150-315L 2-150-315L-Ti
3 18 mm 2-150-318R 2-150-318R-Ti 2-150-318L 2-150-318L-Ti
4 12 mm 2-150-412R 2-150-412R-Ti 2-150-412L 2-150-412L-Ti
4 15 mm 2-150-415R 2-150-415R-Ti 2-150-415L 2-150-415L-Ti
4 18 mm 2-150-418R 2-150-418R-Ti 2-150-418L 2-150-418L-Ti
5 12 mm 2-150-512R 2-150-512R-Ti 2-150-512L 2-150-512L-Ti
5 15 mm 2-150-515R 2-150-515R-Ti 2-150-515L 2-150-515L-Ti
5 18 mm 2-150-518R 2-150-518R-Ti 2-150-518L 2-150-518L-Ti
6 12 mm 2-150-612R 2-150-612R-Ti 2-150-612L 2-150-612L-Ti
6 15 mm 2-150-615R 2-150-615R-Ti 2-150-615L 2-150-615L-Ti
6 18 mm 2-150-618R 2-150-618R-Ti 2-150-618L 2-150-618L-Ti
7 12 mm 2-150-712R 2-150-712R-Ti 2-150-712L 2-150-712L-Ti
7 15 mm 2-150-715R 2-150-715R-Ti 2-150-715L 2-150-715L-Ti
7 18 mm 2-150-718R 2-150-718R-Ti 2-150-718L 2-150-718L-Ti
