Specifications
• Standard 25mm barrel length
• Plates available with 2,3,4,5,6,7,8,9,10,12,14,16,18,20 & 22 holes.
• Shaft of the plate mate with 4.5mm Cortical screw and barrel mate with 12.5mm
DHS/DCS Screws (with Compression Screws)
Indications for use
It is indicated to fix following fractures of the proximal femur-
• Intertrochanteric fractures
• Subtrochanteric fractures
• Basilar Neck fractures
Specifications
• Standard 25mm barrel length
• Plates available with 2,3,4,5,6,7,8,9,10,12,14,16,18,20 & 22 holes.
• Shaft of the plate mate with 4.5mm Cortical screw and barrel mate with 12.5mm
DHS/DCS Screws (with Compression Screws)
Indications for use
It is indicated to fix following fractures of the proximal femur-
• Intertrochanteric fractures
• Subtrochanteric fractures
• Basilar Neck fractures
| Holes | Stainless Steel | Titanium |
|---|---|---|
| 2 | 6-124-02 | 6-124-02Ti |
| 3 | 6-124-03 | 6-124-03Ti |
| 4 | 6-124-04 | 6-124-04Ti |
| 5 | 6-124-05 | 6-124-05Ti |
| 6 | 6-124-06 | 6-124-06Ti |
| 7 | 6-124-07 | 6-124-07Ti |
| 8 | 6-124-08 | 6-124-08Ti |
| 9 | 6-124-09 | 6-124-09Ti |
| 10 | 6-124-10 | 6-124-10Ti |
| 12 | 6-124-12 | 6-124-12Ti |
| 14 | 6-124-14 | 6-124-14Ti |
| 16 | 6-124-16 | 6-124-16Ti |
| 18 | 6-124-18 | 6-124-18Ti |
| 20 | 6-124-20 | 6-124-20Ti |
| 22 | 6-124-22 | 6-124-22Ti |
